Electrical Specifications

Rated Power Output (Watts) 1060
RPM at Rated Output 400
D.C. Current at Rated Output (Amps) 4.24
Required Torque at Maximum Power (NM) 35 (approx.)
Phase Resistance (Ohms) 5.0
Output Wire Size (AWG) 12
Output Wire Length (inches) 24
Generator Configuration 3 Phase Star Connected and Rectified
Design Lifetime >20 Years

Mechanical Specifications

Mounting Configuration Vertical or Horizontal
Weight (lbs) 90
Starting Torque (NM) <2.0
Bearing Type JSU Type-X Sealed Bearings

Material Specifications

Shaft Material A356 - T6 Aluminum
Outer Frame Material A356 - T6 Aluminum
Fasteners (Nuts and Bolts) High Quality Stainless Steel
Generator Temperature Range -40° to 176 ° F (-40° to 80 ° C)
Magnet Material Neodymium Iron Boron
Magnet Temperature Rating 176 ° F (80 ° C)
Manufacturing Origin 100% Made in U.S.A.

Download PWG-1 Data Sheet Here - PDF Format  Download Mounting Dimensions Here - PDF Format
